X1L Elite

Introducing the new X1L Elite.

We took one of the best TIR optics and paired it with the unparalleled Lume X1 constant-current boost driver electronics. Turn night into daylight - for your outdoor adventures and beyond.

Features

• Size - 126mm x 48mm x 28.5mm
• Weight - 165g (without batteries)
• Gaggione LLC59NF Total Internal Reflection Optics (7-deg)
• New Toughened Micro-Arc Oxidation Finishes
• New Firefly High CRI Emitter Options (FFL707A series), Cree XHP70.3 HI, Luminous SFT-70
  • Max Output: ~3800 Lumens (depending on emitter choice)

  • Limited Emitter Option: FFL707A 1800k CRI95 2000LM 'Rosy Sunset' - please contact us for a custom order.

• Battery - unprotected flat-top 21700 (not included, recommended to use high-drain cells including Molicel P42, P45, P50, or Samsung 40T, 50S, or Vapcell T50)
• RGB Auxiliary (front), Illuminated Blue Side Switch with Red Charging Indicator
• CNC Construction, 6063-T6 Alloy, PVD-coated Stainless Steel Bezel

• Lume X1 40W Boost Driver, Constant Current Regulated (up to 95% efficiency) with UDR (Ultra Dynamic Range)
• Be-Cu Silver-Plated Springs
• Toughened Front Glass Lens, AR Coated (~98% transmittance)
• Anodized T-cut Threads
• 10W Fast Charging, Firefly Patented Magnetic Type-C Port (Patent 2023235776065)
• Magnetic Tail Cap (optional add-on)
• Water Resistance - IPX8

Included Accessories

• 1x SS Clip

• 1x Lanyard
• 1x Spare AR-Coated Front Glass
• Spare O-rings

All X1L Elite flashlights come with a standard tailcap with the same finish as the body. An optional black PVD-coated magnetic tailcap is available separately (order here).

Runtime* Table

*Vapcell 21700 T50 Battery

User Interface: (Anduril V2)

This flashlight uses the open-sourced Anduril user interface. Anduril 2 is an open-sourced software and distributed under the terms of GPLv3. The source can be accessed here.

By default, this flashlight begins in Simple UI with 5 brightness levels. Enter the hidden Advanced UI to access additional features and more configuration options. Details can be found in Anduril User Guide.

Charging

X1L Elite features an intelligent 10W battery charger. For optimal charging, use a USB-C port that can source at least 5V 3A. Upon the start of charging, the side-switch illuminates red. When charging is complete, the red indicator turns off. A flashing red indicator indicates a charge fault.

For battery safety, cells below 3V are pre-charged at 100mA before the full 10W charge starts, transitioning to constant voltage, and ending with trickle-charging. The charger includes a 10-hour safety timer to prevent extended charging.

While not recommended, the flashlight may be used while charging, but if operated at higher power levels than the charging rate, the battery will not be charged.

Battery Level Indicator

Anduril2 UI uses the front RGB auxiliary LEDs to indicate the current battery level upon turn-off. The colors correspond as follows:

This post-off display can be turned off or configured in Anduril.

Operation Notes

• The X1L Elite is a high-performance flashlight and can generate a lot of heat during operation. Please understand that this is not a toy and should be handled with safety.
• To prevent accidental activation of the flashlight, it is recommended to lock-out the flashlight (4 clicks from off to lock or unlock) before storage, or unscrew the body slightly as a mechanical lock-out.
• This flashlight has low-voltage protection which cuts off power at 2.8V. It is recommended to begin recharging the cell before this happens to increase battery longevity.
